Rely on high performance, fluoropolymer coating is used across various demanding environments. Today let’s know the different fluoropolymer resin coating properties and process.

Summary of Fluoropolymer Coating Performance Comparison

PTFE(F4) coating

● Low coefficient of friction

● Poor meltability

● Excellent chemical resistance

● PTFE dispersion coating: non-stick, wear-resistant, lubricating with maximum thickness 80um, temperature range -200 °C to +260 °C

● Sheet lining layer: common thickness 3mm, temperature range -30 °C to +130 °C

● Molded layer: typically 8mm-10mm thick, temperature range -30 °C to +210 °C

FEP(F46)coating

● Chemical resistance similar to PFA

● Mechanical resistance less than PFA and PTFE

● Temperature range -190°C to +200°C

● Better non-stick properties than PFA, better leveling properties than ETFE and PFA

● FEP Powder and emulsion spray non-stick coating: 100um, temperature range -180°C to +200°C

● Heavy anti-corrosive powder coating: 2000um, temperature range-150°C to +190°C

● Molded layer thickness usually 8mm-10mm, temperature range -50°C to +180°C

ETFE(F40)coating

● Same stretch performance as PTFE

● Temperature range -50°C to +150°C

● ETFE powder coating for general corrosion protection: 300um, temperature range -50°C to +150°C

● Heavy anti-corrosive powder coating (thick coating) : 1000um, temperature range -50°C to +150°C

● Rotational coating thickness: 0.5mm-4mm, temperature range -30°C to +120°C

PFA coating

● Chemical and mechanical resistance similar to PTFE

● Temperature range -200°C to +260°C

● PFA powder coating (thin coating): 100um, temperature range -190°C to +200°C

● Heavy anti-corrosive powder coating (thick coating): 1000um, temperature range -180°C to +250°C

● Molded layer thickness: 8mm-10mm, temperature range -100°C to +210°C

● Rotational coating thickness: 0.5mm-4mm, temperature range: -190°C to +250°C

ECTFE coating

● Resistant to organic solvents, strong acids, chlorides, and sodium hydroxide

● Excellent impact toughness even at temperatures as low as -40°C

● Temperature range: -50°C to +150°C

● Standard anti-corrosion coating thickness: 300 μm; maximum coating thickness: 1500 μm

● Heavy anti-corrosion sheet lining type: 2.5 mm thickness; temperature range: -30°C to +120°C

Conclusion

As a professional and service-oriented fluoropolymer resin manufacturer,Uflon offer various kinds of fluoropolymer coating solutions catering for customers’ production requirements.

Contact us for further technical support!
